Fujitsu PRIMERGY CX2550 M1 - Onboard Settings

CX2550 M1 Upgrade and Maintenance Manual 215
Appendix
12.2.1.2 Onboard settings
Figure 111: Jumper on system board
Reset RTC
Password Skip
Jumper position Function Default
setting
1-2
Reset RTC enabled
no jumper Reset RTC disabled o
Table 6: Reset RTC
Jumper position Function Default
setting
3-4 PASSWORD CLEAR (SKIP)
no jumper NORMAL MODE o
Table 7: Password skip
