Upgrade and Maintenanc
e Manual
CX2550
M1
Basic hardware procedures
4.10
Inst
alling
the server node
in the ser
ver
enclosure
V
CAUTIO
N!
●
Follow the safety instruc
tions in the chapter
"Important i
nformation"
on page
27
.
Figure 13: Instal
ling the server node
Ê
Push the server node at the handle into the server
enclosure until the locking
mechanism snap
s into place.
Ê
If applicable, connect all external cabl
es to the server node.
49
51
