212 Upgrade and Maintenance Manual CX2550 M1
Appendix
12.1.2 Server node rear
Figure 109: Connection panel of the server node
13 Network controller
1 Shared LAN connector (LAN 1) 5 Video connector
2 Standard LAN connector (LAN 2) 6 PCI2 (connected to PCI slot 11-14
on system)
3 Management LAN connector 7 PCI1 (connected to PCI slot 1-4 on
system)
4 2 x USB 3.0 connectors
