Fujitsu PRIMERGY CX2550 M1 Upgrade And Maintenance Manual
5
of 1
of 1 rating
222 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
40
Upgrade and Maintenanc
e Manual
CX2550
M1
Basic hardware procedures
4.2
Removing the server
nod
e from the server
enclosure
V
CAUTIO
N!
●
Shut down the server node and di
sconnect all external cables
.
●
Follow the safety instruc
tions in the chapter
"Important i
nformation"
on page
27
.
Figure 2: Rem
oving the serv
er node
Ê
Undo the locking mechanism (1) of the release lever and pull
the serv
er
node out of the slot (2).
39
41
Table of Contents
