CX2550 M1 Upgrade and Maintenance Manual 201
Liquid cooling
Figure 100: Example: Memory modules with cooling pads built-in
Pos.
Memory
module
Number of cooling pads
1 1C 1 cooling pad
2, 3 2C 2 cooling pads
4, 5 1D 2 cooling pads
6 2D 1 cooling pad
