Fujitsu PRIMERGY CX2550 M1 - Page 42

42 Upgrade and Maintenance Manual CX2550 M1
Basic hardware procedures
Figure 4: Riser module at the right side
Ê Remove the riser module at the right side accordingly from the chassis by
pulling the riser module out of the slot and the bolt out of the chassis sparing
(see circle).
