If applicable, remove the OCP modules, see "Removing the OCP module"
on page 215.
▶
"Getting access to the component" on page 52.
▶
Remove the air duct, see "Removing the air duct" on page
73.
▶
Remove all fans, see "Removing the defective fan module" on page 192.
▶
Remove all riser modules, see "Removing a riser module" on page 69.
▶
Remove the system board, see "Removing the defective system board" on
page 389.
Removing the defective TPM
▶
Remove the TPM, see "Removing the TPM" on page 353.
▶
Leave the TPM spacer on the system board when removing the defective
TPM.
Installing the new TPM
The TPM spacer is already present on the system board.
▶
Install the TPM, see "Installing the TPM" on page 350.
Concluding steps
▶
Install all riser modules, see "Installing a riser module" on page 69.
▶
Install all fans, see "Installing the new fan module" on page
192.
▶
Install the air duct, see "Installing the air duct" on page 74.
▶
Install the system board, see "Installing the new system board" on page 393.
▶
"Reassembling" on page 57.
▶
If applicable, install the OCP modules, see "Installing the OCP module" on
page 213.
▶
Install all PSUs, see "Installing a hot-plug PSU" on page 108.
▶
"Connecting the power cord" on page 62.
