Fujitsu ScanSnap N1800 User Manual

5.4 Pre-settings for Using Central Admin Console
234
3. Press the [Download] button.
D Follow the instructions displayed on the window.
The following settings will be required. Determine the port number and protocol
to be used in advance.
z Port number for scanner communication
z Port number for Central Admin Console communication
After installation, the port number and protocol settings can be changed on the
Central Admin Console [Scanner Central Admin Server Settings] window.
D After installation is complete, restart the computer.
z Downloading is not possible while a scanner operation is in process.
z Do not close the Web browser or logout until installation is complete.
z Installation requires 700 MB of free disk space, which includes 200 MB
required to install SQL Server 2005 Express Edition.
z If the Central Admin Server is already installed, skip to "5.4.2 Installing the Central
Admin Console" (page 238)
.
z When installing the Central Admin Server over an older version of the software, all
of the old Central Admin system settings should be automatically reused. However,
as a precaution, it is still recommended that the old settings be backed up before
proceeding with the upgrade installation. To back up the Central Admin settings,
refer to
"5.17.1 Backing Up Central Admin Server Settings" (page 281).
z Make sure that the Central Admin Server date and time values are set correctly. If
the date/time difference between the values set in the server and actual values is
large, normal operation may not be possible.
z After the Central Admin Server software is installed, a Windows user account
(Account name: iSCentralAdmin) is added. This user is required for Central Admin
Server, therefore, do not change or delete the account.

Fujitsu ScanSnap N1800 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Output color depth	24 bit
ADF scan speed (color, A4)	20 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (color, A4)	20 ipm
Display	TFT
Scanner type	ADF scanner
Product color	Black, Grey
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Fax, File, FTP, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	12000 pages per month
Daily duty cycle (max)	2000 pages
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Auto document feeder (ADF) input capacity	50 sheets
Safety	LDAP, LDAPS, FTPS, HTTPS
Cabling technology	10BASE-T, 100BASE-TX
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP
Input voltage	100-240 V
Power supply type	AC
Power consumption (off)	0.5 W
Power consumption (standby)	15 W
Power consumption (typical)	50 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Depth	226 mm
Width	300 mm
Height	172 mm
Weight	6000 g
