Section 4
4-50 © Copyright 2009 GBC. All rights reserved. Advanced Punch Service Manual
4. Cut the cable ties on the left wiring harness [1] to free the Punch Module wiring.
Figure 4.53 Wiring Harness at Rear of Punch.
[1]
