Section 5

ITEM PART NO UNIQUE DESCRIPTION QTY.

36 - BRACKET, HINGE, BOTTOM, DOOR 1

37 - BRACKET TOP FRONT DOOR 1

38 - BRACKET,MOTOR COVER 1

39 - COVER LEFT SIDE 1

40 030N00763 BRACKET,DOCKING ASM 1

41 023N01223 BELT, 2 SIDED,3mm PITCH X 6mm WIDTH X 179T 1

42 023N01224 BELT, 2 SIDED, 3mm PITCH X 6mm WIDTH X 232T 1

43 - BACK GAGE ASM 1

44 - CUSHION, DRIVE ARM RUBBER 1

45 002N02895 FRONT DOOR ASSEMBLY 1

46 180N00017 115V PUNCH MODULE, 115V 1

180N00016 230V PUNCH MODULE, 230V 1

47 - SPRING EXTENSION 2

48 600N03353 - FRENCH LANGUAGE LABEL
