ITEM PART NO UNIQUE DESCRIPTION QTY.
1 - SCR, HEX SOC HD, 8-32 X 1/4 1
2 - SCR, PHIL PAN HD, 2
3 - SSCR, PHIL PAN HD, #4-40 X 3/16 2
4 - WSHR, .192 ID X .625 OD X .060 T 8
5 - CABLE CLAMP CIRCULAR TYPE 7
6 - WIRE SADDLE - LOCKING TOP 16
7 - GROMMET, 1 1/4 I.D. X 1 1/2 O.D. 1
8 142N00168 115V RFI POWER FILTER 1
9 142N00169 230V RFI POWER FILTER, 3EP7 1
10 110N01437 INTERLOCK SWITCH 1
11 003N01054 KNOB 1
12 023N01214 BELT, 3MM PITCH X 6MM WIDTH X 84T 1
13 - HOLDER, BRUSH BACK GAGE 1
14 003N01055 LATCH, PUSH TO-CLOSE 1
15 125N00096 BRUSH, BACK GAGE 1
16 023N01217 BELT HTD, 3MM PITCH X 6MM WIDTH X 148T 1
17 003N01056 KNOB, TRANSPORT 1
18 023N01219 BELT, 3MM PITCH X 6MM WIDTH X 100T 4
19 127N07623 Prior to SN UAD235301
LTR SN 308244515 A4
STEPPER MOTOR ASSEMBLY, EXIT 1
19 127N07831 From SN UAD235301
LTR SN 308244515 A4
STEPPER MOTOR ASSEMBLY 1
20 033N00249 FAN COOLING, TRANSPORT (CCW) 1
21 127N07622 Prior to SN UAD235301
LTR SN 308244515 A4
STEPPER MOTOR ASSEMBLY, ENTRANCE 1
21 127N07831 From SN UAD235301
LTR SN 308244515 A4
STEPPER MOTOR ASSEMBLY 1
22 021N02267 CAP, RUBBER .032x1.00 1
23 021N02268 CAP, RUBBER .312 x .250 1
24 - PULLEY, MOTOR HTD TIMING, 3MM PITCH, 24G 1
25 023N01221 BELT, 3MM PITCH X 6MM WIDTH X 98T 1
26 023N01222 BELT, 3MM PITCH X 6MM WIDTH X 156G 1
27 600N03417 115V KIT, MOTOR, TRANSPORT, 115V 1
600N03418 230V KIT, MOTOR, TRANSPORT, 230V 1
28 - DIVERTER SOLENOID ASM 1
29 - COVER, I/O SWITCH 1
30 - CAPACITOR 1
31 050N00544 CHIP TRAY ASSEMBLY 1
32 002N02892 TOP COVER ASSEMBLY 1
33 - COVER REAR LEFT ASM 1
34 - COVER REAR RIGHT ASM 1
35 002N02893 REAR COVER 1
Note there are two versions of Stepper Motors used Items 19 and 21 depending on the serial number of the machine.
Note that there are two versions of the Stepper Motor Driver Boards (reference Electronics PCB Assembly) used depending on
the serial number of the machine.
Old and new Stepper Motors-Driver Boards cannot be mixed.
Note Item 27 is a kit. The Transport Motor in the kit has an adapter plate.
The adapter plate is used with machine serial number prior to UAD235364 (LTR units) and prior to 308244524 (A4 units).
The adapter plate is not used and should be discarded for machines with serial numbers from the ones listed above.
