Section 5

PL 5.8 ALIGNER EXIT, RV, IDLER ASSY

PART NUMBER UNIQUE DESCRIPTION QTY/MACHINE

055N00301 115V ALIGNER EXIT, RV, IDLER, ASSY, LTR 1

055N00305 230V ALIGNER EXIT, RV, IDLER, ASSY, A4 1

ITEM PART NO. UNIQUE DESCRIPTION QTY.

1 - 6 TFAHS 4/1 E GNINIATER ,GNIR

2 - 6 GNIRAEB

3 - 3 TOVIP RENIGILA,TFAHS

4 009N01655 6 RENGILA,NOISROT,GNIRPS

5 022N02418 ASSY,ALIGNER, IDLER ROLLER 1

6 022N02414 ALIGNER, PLASTIC IDLER ROLLER ASSEMBLY 2

7 -

115V

ALIGNER,RV,EXIT IDLER,WELDMENT, LTR 1

230V

ALIGNER,RV,EXIT IDLER,WELDMENT, A4 1

8 600N03327 TIK YSSA RELLOR RELDI

8.1 - 1 YSSA RELLOR RELDI

8.2 - 2 NOISNETXE GNIRPS

8.3 - BEARING ASSY 4 ROLLER DRIVE 2
