Parts List
Advanced Punch Service Manual © Copyright 2009 GBC. All rights reserved. 5-23
PL 5.9 PAPER GUIDE BYPASS, UPPER, ASSY
DESCRIPTION QTY/MACHINE
PAPER GUIDE BYPASS, UPPER, ASSY 1
ITEM PART NO. DESCRIPTION QTY.
2 NOISNETXE GNIRPS - 1
2 - STEEL STRIKE,MAGNETIC CATCH 3
3 - BEARING ASSY 4 ROLLER DRIVE 2
4 - BYPASS,RV,PAPER GUIDE WELDMENT 1
5 - IDLER, EXIT ROLLER ASSEMBLY 1
6 - SCR,PHL PAN HD, 4-40 X 1.13 1
1 04-4,SPEK ,RHSW & TUN - 7
1 EVITCELFER ,ROSNES - 8
9 600N03325 IDLER 2 ROLLER ASSEMBLY KIT
9.1 - IDLER 2 ROLLER ASSEMBLY 3
9.2 - BEARING, DOUBLE D FLANGE 6
6 NOISNETXE GNIRPS - 3.9
10 600N03326 SENSOR, REFLECTIVE KIT
1 EVITCELFER ,ROSNES - 1.01
1 04-4,SPEK ,RHSW & TUN - 2.01
10.3 -
SCREW,MACHINE PAN #4-40 X
15/32 PHILLIPS
1
