Repair and Adjustment Procedures
Advanced Punc
h Service Ma
nual
© Copyright 2009 GBC. All rights reser
ved.
4-9
3.
Unplug the
entran
ce side sensor at the
rear frame [1]
.
Figure 4.9 Sensor Conne
ctor on Entrance Side.
4.
F
rom the rear of t
he punch, remo
ve one of the
E-r
ings from the Byp
ass
shaft
[1].
Figure 4.10 Remove E-Ring.
[1]
[1]
66
