GE VOLUSON
i / VOLUSON
e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
3-38 Section 3-5 - Connection of Auxiliary Devices
3-5-3-3 Installation of the Additional Shelf Peripherals
1.) Place the Additional Shelf and fasten it with the 2 screws.
3-5-3-4 Installation of the Console Bottom Shelf
1.) Place the Console Bottom Shelf and fasten it with the 2 screws.
3-5-3-5 Installation of the Cover BW Printer Shelf
1.) Align tab on the front of the Printer Shelf Cover with the slot in front of the Printer Shelf;
press down and snap into place.
Figure 3-42 Installation Additional Shelf Peripherals
Figure 3-43 Installation Console Bottom Shelf
Figure 3-44 Installation Cover BW Printer Shelf
