GE VOLUSON i / VOLUSON e
D
IRECTION KTI106052, REVISION 10 SERVICE MANUAL
5-20 Section 5-3 - Front End Processor
5-3-4 Probe and MUX Board (RPM)
The Probe and MUX (multiplexer) Board enables acquisition and processing of signals from and to
probes connected to the front panel. The RPM Board has 192 receive/transmit channels, and performs
the following functions:
• Receiving the channels and connecting them to the RBF Boards
• Probe connector (mounted via a flex print)
• High voltage MUX that selects 64 out of 192 inputs
