8-40 Section 8-18 - Replacement of the Modo Cart Components
Section 8-18
Replacement of the Modo Cart Components
For quick reference, the Modo Cart component replacement procedures are described in the following
sub-sections:
8-18-1 Replacement of the Probe Holders
8-18-1-1 Manpower
One person, 5 minutes
8-18-1-2 Tools
none
8-18-1-3 Preparations
none
8-18-1-4 Probe Holder - Removal Procedure
1.) Remove the Probe Holder.
8-18-1-5 Probe Holder - Installation Procedure
1.) Place the new Probe Holder.
Table 8-2 Optional Peripherals and Accessories - Replacement Parts
Sub-section Description Page Number
8-18-1
Replacement of the Probe Holders
8-40
8-18-2
Replacement of the Cable Clips
8-41
8-18-3
Replacement of the Fuses
8-42
8-18-4
Replacement of the Wheels
8-43
Figure 8-55 Remove the Probe Holder
