6-8
The CE6000-120AP analyzes the cutting data, and controls the angle of the cutter blade tip if the change in the
angles of the corner is large.
Angle control is applied if there is larger angle change than the angle specified as reference angle.
The time to cut is shortened by setting large value for the reference angle, since it will only apply blade control
when there are angles with large angle change, hence reducing the time to make the blade control.
But, if it is set too large, there will be not enough angle control of the blade, and the cut result may differ from what
was expected. Set the reference angle in good balance.
Supplement
This setting is maintained even if the power is turned off.
Operation
Supplement
Perform the settings in Normal menu.
1 Press the [PAUSE/MENU] key.
MENU screen is displayed.
2 Press the [1] key (TOOL).
TOOLS SETTING screen (1/3) is displayed.
3 Press the POSITION ( ) key.
TOOL SETTING screen (2/3) is displayed.
4 Press the [1] key (OFFSET ANGLE).
OFFSET ANGLE screen is displayed.
Supplement
Setting range is from 0 to 60.
5 Press the POSITION ( ) key and increase or decrease the
setting value.
6.3
Setting the Offset Angle
