GRAPHTEC CE6000-120AP - Changing and Saving the RS-232 C Interface Setting

8-5
Changing and saving the RS-232C interface setting
Operation
1 Press [PAUSE/MENU] key in default screen.
MENU screen is displayed.
MENU screen
(Simple menu)
MENU screen
(Normal menu)
2 Press POSITION ( ) key (I/F) in Normal menu, press [2] key
(I/F) in Simple menu.
INTERFACE SETTING screen is displayed.
INTERFACE setting screen
(Simple menu)
INTERFACE setting screen
(Normal menu)
3 Press POSITION ( ) key (I/F) in Normal menu.
INTERFACE setting screen (2/3) is displayed.
INTERFACE setting screen
(Simple menu)
INTERFACE setting screen
(Normal menu)
4 Press the [2] key (RS-232C).
RS-232C setting screen is displayed.
Supplement
Baud rate can be set to 19200, 9600, 4800,
2400, 1200, 600, and 300.
5 Press the [1] key (BAUD RATE).
BAUD RATE setting screen is displ ayed.
