GRAPHTEC CE6000-120AP - A.5 Initial Setting

A-11
Simple Menu
Menu items Setting items Initial value
MEDIA PAGE LENGTH 300.0cm
PAPER LOAD FUNCTION 2
INTERFACE SELECT USER 1
RS-232C (Forwarding condition) Baud rate: 9600
Data length: 8-bit
Parity: no
Hardwire: Handshake
ADVANCE LENGTH UNIT Select when initially turning on power
TOOLS CONDITION Same as Normal menu
* The initial values of setting items are subject to change.
Normal Menu
Menu items Setting items Initial value
TOOLS SETTING BLADE WEAR SETUP OFF
STEP PASS 1
OFFSET FORCE 4
OFFSET ANGLE 30
DATA SORTING ON
TOOL UP SPEED AUTO
CONDITION PRIORITY PROGRAM
INITIAL BLADE CONTROL POSITION 2 mm BELOW
TOOL UP MOVE DISABLED
AXIS ALIGNMENT AXIS ALIGNMENT OFF
AREA PARAMETER SETTINGS EXPAND DEFAULT
ROTATE OFF
AREA (LOWER LEFT) DEFAULT
AREA (UPPER RIGHT) DEFAULT
DISTANCE ADJUST X 0.00%
DISTANCE ADJUST Y 0.00%
MEDIA SETTING `F`COMMAND CUT OFF
CROSS CUT FORCE 20
CROSS CUT ON
PAGE LENGTH 300.0cm
AUTO PRE FEED OFF
FEED SPEED NORMAL
INITIAL FEED ON
PAPER LOAD FUNCTION 2
PEPER READY TIME 180 sec
PANEL CUTTING OFF
DIVIDE LENGTH 100.0cm
SPACEREAR 7.0mm
INTERFACE SELECT USER 1
COMMAND HP-GL
HP-GL ORIGIN POINT LOWER LEFT
HP-GL MODEL EMULATED 7586
GP-GL STEP SIZE 0.100mm
RS232C (SWITCHING SETTING) Baud rate: 9600
Data length: 8-bit
Parity: no
Hardwire: Handshake
GP-GL SEPARATOR _
HP-GL SEPARATOR _
TIME OUT 0 sec.
COMMAND ' : ', ' ; ' ENABLING
COMMAND 'W' TOOL UP
CIRCLE RESOLUTION DEFAULT
A.5
Initial Setting
