6-19
3 Press [2] key (BLADE WEAR SETUP).
BLADE WEAR SETUP screen is displayed.
Supplement
Press [4] key (CANCEL) to return to the BLADE
WEAR SETUP screen without changing any
settings.
4 Press [3] key (SET FACTOR).
The FACTOR setting screen is displayed.
* Display may vary depending on the selected tool condition number.
5 Press the POSITION ( )keys to select the tool condition
number (CONDITION No.).
Supplement
You can set the range between 0.1 and 3.0.
6 Press the POSITION ( ) key and increase or decrease the
setting value.
Supplement
It will return to BLADE WEAR SETUP screen
without changing the settings when you press
the POSITION (
) key (CANCEL).
7 Confirm the setting and press the [ENTER] key (SET).
Setting will be set, and it will return to BLADE WEAR SETUP screen.
8 Press the [PAUSE/MENU] key.
It will return to default screen.
