FC8000-UM-251-9370 9-1

9. PARTS LIST

9.1 Outer Casing

No. PartNo. Description Q’ty Remarks Rank

1 621404011 RightSideCover 1 C

621524010 RightSideCover89 1 89series C

2 621404001 LeftSideCover 1 C

621524000 LeftSideCover89 1 89series C

3 621404111 CenterCover60 1 FC8000-60 C

621414212 CenterCover75 1 FC8000-75/ C

621424212 CenterCover100 1 FC8000-100 C

621434211 CenterCover130 1 FC8000-130 C

621444211 CenterCover160 1 FC8000-160 C

621524200 CenterCover8924 1 8924 C

621534200 CenterCover8930 1 8930 C

621544200 CenterCover8942 1 8942 C

621554200 CenterCover8954 1 8954 C

621564200 CenterCover8964 1 8964 C

363013061 RubberStopper 1 C

4 621390081 FrontGuide60 1 FC8000-60 C

621261085 FrontGuide75 1 FC8000-75 C

621271086 FrontGuide100 1 FC8000-100 C

621281086 FrontGuide130 1 FC8000-130 C

621291086 FrontGuide160 1 FC8000-160 C

5 621390091 RearGuide60 1 FC8000-60 C

621261096 RearGuide75 1 FC8000-75 C

621271096 RearGuide100 1 FC8000-100 C

621281096 RearGuide130 1 FC8000-130 C

621291096 RearGuide160 1 FC8000-160 C

6 621400101 FrontWritingPanel60 1 FC8000-60 C

621410101 FrontWritingPanel75 1 FC8000-75 C

621420101 FrontWritingPanel100 1 FC8000-100 C

621430101 FrontWritingPanel130 1 FC8000-130 C

621440101 FrontWritingPanel160 1 FC8000-160 C

7 621390041 RearWritingPanel60 1 FC8000-60 C

621261044 RearWritingPanel75 1 FC8000-75 C

621271044 RearWritingPanel100 1 FC8000-100 C

621281044 RearWritingPanel130 1 FC8000-130 C

621291045 RearWritingPanel160 1 FC8000-160 C

8 792800700 MainBoardforFC8000 1 FC8000 A

792800770 MainBoardfor89series 1 8924/8930/8942/8954/8964 C

9 682140120 SwitchingPowerSupplyUnit 1 C

10 363024101 Foot(NT24) 4 C

11 500052449 Fan(TDS-05B-DC12V) 1 B

12 621390470 CuttingMat60 1 FC8000-60,8924 A

621261470 CuttingMat75 1 FC8000-75,8930 A

621271073 CuttingMat100 1 FC8000-100,8942 A

621281073 CuttingMat130 1 FC8000-130,8954 A

621291073 CuttingMat160 1 FC8000-160,8964 A

13 621390060 Base,CuttingMat60 1 FC8000-60,8924 C

621261060 Base,CuttingMat75 1 FC8000-75,8930 C

621271060 Base,CuttingMat100 1 FC8000-100,8942 C

621281060 Base,CuttingMat130 1 FC8000-130,8954 C

621291060 Base,CuttingMat160 1 FC8000-160,8964 C

14 792800707 LANBoard 1 Option B

15 621401721 I/FPanel,STD 1 ForwithoutLANBoard B

621401711 I/FPanel,LAN 1 ForLANBoardOption B

16 621404021 Cap,Cover 2 C

621524020 Cap,Cover89 2 89series C
