4. RECOMMENDED PARTS LIST
4. RECOMMENDED PARTS LIST
No. PartNo. Description -60 -75 -100 -130 -160 Remarks
1 792800700 MainBoard 1 1 1 1 1
2 682140120 SwitchingPowerSupplyUnit 1 1 1 1 1
3 500052478 CamSensor,LG-217D-3 1 1 1 1 1
4 500051382 MediaSensor,PS-117ND-1 2 2 2 2 2 PaperSensor
5 682126200 Motor,X 1 1 – – – Xmotor
682132430 Motor,X – – 1 1 1
6 682126200 Motor,Y 1 1 1 1 1 Ymotor
7 792800702 PenRelayBoard 1 1 1 1 1
8 792800703 PinchRollerSensorBoard 1 1 1 1 1
9 792800704 RegistrationMarkSensorBoard 1 1 1 1 1
10 792800705 CamSensorBoard 1 1 1 1 1
11 792800706 ControlPanelBoard 1 1 1 1 1
12 792800707 LANBoard 1 1 1 1 1 Option
13 692140321 FlexiblePrintedCable,FPC707102 1 1 1 1 1
ControlPanel20P
14 692140330 YFlexiblePrintedCable,FPC707103,60/75 1 1 – – – FC8000-60/75
692140340 YFlexiblePrintedCable,FPC707105 – – 1 – – FC8000-100
692140350 YFlexiblePrintedCable,FPC707105 – – – 1 – FC8000-130
692140360 YFlexiblePrintedCable,FPC707106 – – – – 1 FC8000-160
15 692140310 FlexiblePrintedCable,FPC707101A 1 1 1 1 1
ControlPanelFlexibleCable16Pin
16 792800708 PenBlockAssembly(PenCarriage) 1 1 1 1 1
17 792800709 LightPointerAssembly 1 1 1 1 1
18 500052451 Fan,KLDC12B4-940 1 1 2 2 2
19 682140130 LCD,JMS12864-15ABAYD 1 1 1 1 1
20 772126570 ControlPanelBaord 1 1 1 1 1
21 792800711 CrossCutterAssy 1 1 1 1 1
22 621391220 YBelt60,150S2M1000 1 – – – –
621261220 YBelt75,150S2M-1150 – 1 – – –
621271220 YBelt100,300S2M-1450 – – 1 – –
621281220 YBelt130,300S2M-1750 – – – 1 –
621291220 YBelt160,300S2M-2010 – – – – 1
23 621392020 DriveRollerset60 1 – – – –
621262020 DriveRollerSet75 – 1 – – –
621272020 DriveRollerSet100 – – 1 – –
621282020 DriveRollerSet130 – – – 1 –
621292020 DriveRollerSet160 – – – – 1
24 095002121 PushRoller 2 2 3 3 3
25 378413041 130TN15-10W,MotorBelt 2 2 2 2 2
26 095013010 RollerBB13,YSliderRoller 7 7 7 7 7
27 621399900 CuttingMat,20mroll 1 1 1 1 1
