GRAPHTEC FC8000-75 - How to Replace the Center Cover

FC8000-UM-251-9370 6-4
6. DISASSEMBLY AND REASSEMBLY
6.1.4 How to Replace the Center Cover
How to detach the center cover
(1) Detachtherightsidecover(seeSubsection6.1.1).
(2) Detachthecontrolpanelassembly(seeSubsection6.1.3).
(3) RemovethesixM3L6bindingheadscrewsholdongthecentercover.
M3L6bindingheadscrew
Centercover
(4) Detachthecentercover.
How to reinstall the center cover assembly
(1) Reattachthecentercoverinthereverseorderinwhichitwasdetached.
