GRAPHTEC FC8000-75 - How to Replace the Y-Relay Board

FC8000-UM-251-9370 6-19
6. DISASSEMBLY AND REASSEMBLY
6.2.8 How to Replace the Y-relay Board
How to detach the Y-relay board
(1) Detachthecentercover(seeSubsection6.1.4).
(2) Removethetwoplasticrivetsattachingtheexiblecableholdingplate.
Plasticrivet
Flexiblecableholdingplate
(3) DisconnectallthecablesfromtheY-relayboard.
(4) RemovethetwoM3L6bindingheadscrewsattachingtheY-relayboard.
Yrelayboard
M3L6bindingheadscrew
(5) DetachtheY-relayboardfromtheY-slider.
How to reinstall the Y-relay board
(1) ReattachtheY-relayboardinthereverseorderinwhichitwasdetached.
