GRAPHTEC FC8000-75 - Page 50

FC8000-UM-251-9370 6-18
6. DISASSEMBLY AND REASSEMBLY
How to reinstall the pinch roller sensor
(1) Attachthepinchrollerbrackettothepinchrollersensorboard.
(2) Connectthepinchrollerexiblecabletothepinchrollersensorboard.
(3) Attachthepinchrollersensorguardtothepinchrollersensorboardbracket.
(4) AttachthepinchrollerbrackettotheY-slider.
 FitthetopandleftedgesofthepinchrollerbrackettotheY-sliderasshowninthegurebelow.
M3L6bindingheadscrew
Pinchrollersensorbracket
(5) Attachthepenblock(seeSubsection6.2.5).
(6) Reattachtheotherpartsinthereverseorderinwhichtheyweredetached.
