GRAPHTEC FC8000-75 - Main Frame

FC8000-UM-251-9370 9-8
9. PARTS LIST
9.6 Main Frame
No. PartNo. Description Q’ty Remarks Rank
1 621390010 MainChassis60 1 FC8000-60 D
621261014 MainChassis75 1 FC8000-75 D
621271014 MainChassis100 1 FC8000-100 D
621281014 MainChassis130 1 FC8000-130 D
621291014 MainChassis160 1 FC8000-160 D
2 621390021 SubChassis60 1 FC8000-60 D
621261024 SubChassis75 1 FC8000-75 D
621271025 SubChassis100 1 FC8000-100 D
621281024 SubChassis130 1 FC8000-130 D
621291024 SubChassis160 1 FC8000-160 D
3 621401052 RightSidePlate 1 D
4 378413041 XDriveBelt,130TN15-10W 1 A
5 010012022 XMotorPulley,Z24 1 A
6 621401131 CableBracket 1 D
7 621401081 RightSideSubPlate 1 D
8 621402000 Pulley,XDriveShaft,TN15-85Z 1 A
9 Bush,D8L21 1 D
10 621392010 XDriveRollerShaft60 1 FC8000-60 C
621262010 XDriveRollerShaft75 1 FC8000-75 C
621272010 XDriveRollerShaft100 1 FC8000-100 C
621282010 XDriveRollerShaft130 1 FC8000-130 C
621292011 XDriveRollerShaft160 1 FC8000-160 C
11 682132430 XMotor,UGJMEE-A7JGR34 1 FC8000-100/130/160 A
682126200 XMotor,DMN37HE-003 1 FC8000-60/75 A
12 500052515 MediaSensor,PS-117ED1 2 A
13 621260011 PillowBlock 5 FC8000-60/FC8000-75 D
621260011 PillowBlock 7 FC8000-100 D
621260011 PillowBlock 9 FC8000-130 D
621260011 PillowBlock 11 FC8000-160 D
14 621260132 MediaSensorBracket 1 D
15 310014820 Bearing,MR148ZZMC3PS2S 5 FC8000-60/FC8000-75 C
310014820 Bearing,MR148ZZMC3PS2S 7 FC8000-100 C
310014820 Bearing,MR148ZZMC3PS2S 9 FC8000-130 C
310014820 Bearing,MR148ZZMC3PS2S 10 FC8000-160 C
16 392040140 Bush,D4L14 1 D
17 621392020 XDriveRollerSet60 1 FC8000-60 A
621262020 XDriveRollerSet75 1 FC8000-75 A
621272020 XDriveRollerSet100 1 FC8000-100 A
621282020 XDriveRollerSet130 1 FC8000-130 A
621292020 XDriveRollerSet160 1 FC8000-160 A
18 621260021 BearingCover 4 FC8000-60/FC8000-75 C
621260021 BearingCover 5 FC8000-100 D
621260021 BearingCover 6 FC8000-130 D
621260021 BearingCover 6 FC8000-160 D
19 792800705 CamSensorBoard 1 A
20 621401031 LeftSideSubPlate D
21 621401003 LeftSidePlate D
22 500052451 Fan,KLDC12B4-940 1 FC8000-75/60 A
500052451 Fan,KLDC12B4-940 2 FC8000-100,130,160 A
