GRAPHTEC FC8000-75 - Wiring Harness

FC8000-UM-251-9370 9-13
9. PARTS LIST
9.9 Wiring Harness
No. PartNo. Description Q’ty Remarks Rank
1 692140080 Cable,CA707108(MediaSensortoMainBoard) 1 C
2 692140090 Cable,CA707109(FantoMainBoard) 1 FC8000 C
692140100 Cable,CA707110(FantoMainBoard) 1 FC8000-100 C
692140110 Cable,CA707111(FantoMainBoard) 1 FC8000-130/160 C
3 692140011 Cable,CA707101A(PowerSupplySwitchtoMainBoard) 1 FC8000-60/75 C
692140021 Cable,CA707102A(PowerSupplySwitchtoMainBoard) 1 FC8000-100 C
692140031 Cable,CA707103A(PowerSupplySwitchtoMainBoard) 1 FC8000-130 C
692140041 Cable,CA707104A(PowerSupplySwitchtoMainBoard) 1 FC8000-160 C
4 692140120 Cable,CA707112(MainBoardtoCamSensor) 1 C
5 692140310 FlexibleCable,FFC707101(PinchRollerSensor) 1 C
6 692140321 FlexibleCable,FFC707102A(MainBoardJ3toControlPanelBoardJ1) 1 B
7 692140371 FlexibleCable,FFC707107A(MainBoardJ22toControlPanelBoard) 1 B
8 692140181 Cable,CA707118A,XMotorExtensionCable 1 FC8000-100/130/160 C
9 692140240 Cable,CA707124,XMotorCable 1 FC8000-60/75 C
10 692140250 Cable,CA707125,XMotorEncoderCable 1 FC8000-60/75 C
11 692140240 Cable,CA707124,YMotorCable 1 C
12 692140250 Cable,CA707125,YMotorEncoderCable 1 C
13 692140330 YFlexibleCable,FPC707103 1 FC8000-60/75 A
14 692140340 YFlexibleCable,FPC707104 1 FC8000-100 A
15 692140350 YFlexibleCable,FPC707105 1 FC8000-130 A
16 692140360 YFlexibleCable,FPC707106 1 FC8000-160 A
