GRAPHTEC FC8000-75 - Pen Block

FC8000-UM-251-9370 9-4
9. PARTS LIST
9.3 Pen Block
No. PartNo. Description Q’ty Remarks Rank
1 792219702 PenHolderAssy4200 1 For2-penmodel A
2 621403030 CutterPenHolder 1 C
3 621353010 ThumbScrewL10 1 B
4 621403000 PenArm 1 C
5 621263230 SlideShaft 1 C
6 682126520 MovingCoilwithYoke(PM1306) 1 C
7 617363351 PenEncoderStrip 1 C
8 692140400 PenFlexibleCable,FPC7071110 1 C
9 380205511 PenArmSpringE-551 1 C
10 792800709 LightPointerAssy 1 A
11 621263251 BearingRollerBaseBracket 1 C
12 310068320 BearingRoller 2 683ZZMC3PS2S C
13 621403010 MovingCoilBase 1 C
14 500050122 EncoderSensor,HEDS-9720#P50 1 C
15 - RegistrationMarkSensorAssy 1 SeeRegistrationMarkSensorAssyPart -
16 792800711 CrossCutterAssy 1 B
17 621113520 Rubberplate 1 C
18 622192091 ArmSpring2 1 For2-penmodel
Thesepartsareincluding
inthe2-penoptionkit.
Thereforethesepartsarenot
suppliedasspareparts.
D
19 622192070 LockArm 2 D
20 053203420 Magnet 2 D
21 622192060 PenHolderAP 2 D
22 337120250 ShaftPinD2L25H7 2 D
23 333302001 StopperRingCS2mm 4 D
24 621409851 PenHolderSpacer 1 D
25 622192081 ArmSpring1 1 D
26 792219703 PenStationAssy4200 1 For2-penmodel B
27 792800708 PenBlockAssy A
