GRAPHTEC FC8000-75 - Explanation of the Values of the Main Board Settings

FC8000-UM-251-9370 7-9
7. ADJUSTMENT
7.3.2 Explanation of the Values of the Main Board Settings
(Default factory settings)
Thedefaultfactorysettingsarerecordedinthelocationshownbelow.
Thedefaultfactorysettings
arerecordedhere.
Thecontentsofanexamplerecordareshownbelow.
 25 47 100 228 346
 X=0 X=80 X=-
 Y=4 Y=50 Y=-
Explanation of the values
Penforcevalues
10g 40g 120g 300g 450g(400g)
Distanceadjustmentvalues Gainadjustmentvalues Autoregistrationmarkpositionadjustmentvalues
X X X
Y Y Y
Youcaninputthesamevalueswhenyouhavereplacedthemainboardwithoutmakinganyadjustments.
Ifyouhavechangedanyvaluesbymakingadjustments,recordthosevaluesforthenextmaintenancecheck.
