6. DISASSEMBLY AND REASSEMBLY
6.2.6 How to Replace the Y-belt
How to detach the Y-belt
(1) Detachtherightandleftsidecovers(seeSubsection6.1.1andSubsection6.1.2).
(2) Detachthecentercover(seeSubsection6.1.4).
(3) Detachthepenblock(seeSubsection6.2.5).
(4) LoosenthetwoM3L35bindingheadscrewsadjustingtheY-belttension.
M3L35bindingheadscrew
(5) RemovethefourM3L6bindingheadscrewsattachingtherightandleftY-beltstopperplatestothe
slider.
Ybelt
M3L6bindingheadscrew
(6) DetachtheY-beltfromtheunit.
