GRAPHTEC FC8000-75 - Registration Mark Sensor Assy

FC8000-UM-251-9370 9-6
9. PARTS LIST
9.4 Registration Mark Sensor Assy
No. PartNo. Description Q’ty Remarks Rank
1 621403200 Spring,CoverDown 1 C
2 621263340 Spring,RMSUp 1 C
3
500052472
Core,Solenoide 1 B
4 Solenoide 1
5 621263312 Bracket,RMSsensor 1 C
6 792800704 RegistrationMarkSensorBoard 1 A
7 621263322 PaperHoldDownA 1 C
8 621263331 PaperHoldDownB 1 C
Registration Mark Sensor Assy
1
3
2
6
4
7
8
5
