GRAPHTEC FC8000-75 - 8.2 Media Loading Operations

FC8000-UM-251-9370 8-2
8. TROUBLESHOOTING
8.2 Media Loading Operations
Symptom Verication item Solution
Themediadropstothe
frontoftheplotter.
(1) Isthefrontedgeofthemedia
curled?
Yes....Replacethemedia.
No.....Verifyitem(2).
(2) Isthefrontmediasensordirty? Yes....Cleanthefrontmediasensor.
No.....Verifyitem(3).
(3) Isthefrontmediasensorcable
securelyconnectedtothemain
boardandthesensor?
Yes....Replacethefrontmediasensor.
No.....Connectthecablesecurely.
Themediadropstothe
rearoftheplotter.
(1) Istherearedgeofthemedia
curled?
Yes....Replacethemedia.
No.....Verifyitem(2).
(2) Istherearmediasensordirty? Yes....Cleantherearmediasensor.
No.....Verifyitem(3).
(3) Istherearmediasensorcable
securelyconnectedtothemain
boardandthesensor?
Yes....Replacetherearmediasensor.
No.....Connectthecablesecurely.
Theplotterdisplays
“LOADMEDIA!”when
mediahasbeenloaded.
(1) Doesthecamsensorplateblock
thecamsensor?
Yes....Checkthecamsensorplateand
attachitatthecorrectposition.
No.....Verifyitem(2).
(2) Isthecamsensorcablesecurely
connectedtothemainboardand
thesensor?
No.....Connectthecablesecurely.
Yes....Replacethecamsensorboard.
Theplottercan’t
recognizetheYdirection
ofthemediasize.
(1) Isthereanydustonthepinch
rollersensor?
Yes....Cleanthepinchrollersensor.
No.....Verifyitem(2).
(2) Isthepinchrollersensorexible
cablesecurelyconnectedto
eachconnector?
Yes....Replacethepinchrollersensor.
No.....Connectthecablesecurely.
Theplottercan’t
recognizetheXdirection
ofthemediasize.
(1) Isthereanydustonthefront
mediasensorandtherearmedia
sensor?
Yes....Cleanthefrontmediasensorand
therearmediasensor.
No.....Verifyitem(2).
(2) Arethefrontmediasensorand
therearmediasensorcables
securelyconnectedtoeach
connector?
No.....Connectthecablessecurely.
Yes....Replacethesensor(s).
Themediaisfedatan
angle.
(1) Arethepinchrollersworndown? Yes....Replacethepinchroller(s).
No.....Verifyitem(2).
(2) Isthereanythingonthedrive
roller?
Yes....Cleanthedriverollerwithabrush.
No.....Verifyitem(3).
(3) Dothepinchrollershavethe
correctpressure?
No.....Replacethepinchrollerspring(s).
Yes....Verifyitem(4).
(4) Isthedriverollerworndown? Yes....Replacethedriveroller.
No.....Verifyitem(5).
(5) Isthedriverollerattached
correctly?
Yes....Replacethebearingofthedrive
roller.
No.....Attachthedriverollercorrectly.
