GRAPHTEC FC8000-75 - How to Replace the Rear Guide

FC8000-UM-251-9370 6-6
6. DISASSEMBLY AND REASSEMBLY
6.1.6 How to Replace the Rear Guide
How to detach the rear guide
(1) RemovethefourM3L6bindingheadscrewsfromtherearguidefortheFC8000-60/75.
(RemovetheveM3L6bindingheadscrewsfromtherearguidefortheFC8000-100.
RemovethesixM3L6bindingheadscrewsfromtherearguidefortheFC8000-130.
RemovethesevenM3L6bindingheadscrewsfromtherearguidefortheFC8000-160.)
(2) Detachtherearguide.
Rearguide
M3L6bindingheadscrew
How to reinstall the rear guide
(1) Reattachtherearguideinthereverseorderinwhichitwasdetached.
