GRAPHTEC FC8000-75 - How to Replace the Cam Sensor

FC8000-UM-251-9370 6-20
6. DISASSEMBLY AND REASSEMBLY
6.2.9 How to Replace the Cam Sensor
How to detach the cam sensor
(1) Detachtherightsidecover(seeSubsection6.1.1).
(2) Disconnectthecablefromthecamsensor.
M3L6bindingheadscrew
Camsensor
(3) RemovetheM3L6bindingheadscrewattachingthecamsensor.
How to reinstall the cam sensor
(1) Reattachthecamsensorinthereverseorderinwhichitwasdetached.
