GRAPHTEC FC8000-75 - How to Replace the Front Guide

FC8000-UM-251-9370 6-5
6. DISASSEMBLY AND REASSEMBLY
6.1.5 How to Replace the Front Guide
How to detach the front guide
(1) RemovethefourM3L6bindingheadscrewsfromthefrontguidefortheFC8000-60/75.
(RemovetheveM3L6bindingheadscrewsfromthefrontguidefortheFC8000-100.
RemovethesixM3L6bindingheadscrewsfromthefrontguidefortheFC8000-130.
RemovethesevenM3L6bindingheadscrewsfromthefrontguidefortheFC8000-160.)
(2) Detachthefrontguide.
Frontguide
M3L6bindingheadscrew
How to reinstall the front guide
(1) Reattachthefrontguideinthereverseorderinwhichitwasdetached.
