6. DISASSEMBLY AND REASSEMBLY
6.2.16 Home Dog Position
Home dog position
Adjustthehomedogpositionwhenyouremoveorreplacethedogasshownbelow.
Ifyouhaveanerroraboutthepinchrollerposition,conrmpositionofthisdog.
115mm
Homepositiondog
6.2.17 Cross Cutter Dog Position
Cross cutter dog position
Adjustthecrosscutterpositiondogwhenyouremoveorreplacethedogasshownbelow.
91mm
Crosscutterpositiondog
