GRAPHTEC FC8000-75 - Page 48

FC8000-UM-251-9370 6-16
6. DISASSEMBLY AND REASSEMBLY
How to reinstall the Y-belt
(1) Shave2to3mmoffbothendsoftheY-beltuntilthewirecomesoutasshownbelow.
Y-belt
Shave 2 to 3 mm off both ends of
the Y-belt until the wire comes out.
(2) HangtheY-beltonbothsidesofthepulley.
(3) AttachbothendsoftheY-belttotheY-slidersothatfournotchesoftheY-belttintotheY-slider,then
attachwiththeY-beltstopperplatesremovedinstep(5)intheprevioussubsection.
M3L6bindingheadscrew
Ybelt
FournotchesoftheY-belttinto
theY-slider.
(4) Attachthepenblock(seeSubsection6.2.5).
(5) Reattachtheotherpartsinthereverseorderinwhichtheyweredetached.
(6) PerformtheY-belttensionadjustment.(seeSubsection7.2.1).
