7-4 7. CHINO
D (Data)
Address Denotations
Name
Decimal
Place
Command
Address (BIN) Parameter 1 (BCD) Parameter 2 (BCD) Read Write
00 0 0 Pattern No. -
1, 1
-
01 0 0 Step No. -
1, 1
-
02 0 0 PV status -
1, 1
-
03 0 0 PV (measurement value) 4
1, 1
-
04 0 0 SV (setting value) 4
1, 1
-
05 0 0 Time display method -
1, 1 2, 8
06 0 0 Time unit 1 -
1, 1
-
07 0 0 Time 2
1, 1
-
08 0 0 MV1 status -
1, 1
-
09 0 0 MV1 2
1, 1 2, 3
0a 0 0 MV2 status -
1, 1
-
0b 0 0 MV2 2
1, 1 2, 3
0e 0 0 Execution target SV 4
1, 2
-
0f 0 0 Execution P 1
1, 2 2, 2
10 0 0 Execution I -
1, 2 2, 2
11 0 0 Execution D -
1, 2 2, 2
12 0 0 Execution AL1 4
1, 2 2, 2
13 0 0 Execution AL2 4
1, 2 2, 2
14 0 0 Execution AL3 4
1, 2 2, 2
15 0 0 Execution AL4 4
1, 2 2, 2
16 0 0 Execution OL 1
1, 2 2, 2
17 0 0 Execution OH 1
1, 2 2, 2
18 0 0 Execution change amount (OSL) 1
1, 2 2, 2
19 0 0 Execution sensor offset 4
1, 2 2, 2
1a 0 0 SV value offset 4
1, 2 2, 2
1b 0 0 2nd P 1
1, 2
-
1c 0 0 2nd I -
1, 2
-
1d 0 0 2nd D -
1, 2
-
20 0 0 Controller / setting device -
1, 6
-
21 0 0
Setting device / thermoelectric
type / resistance type
-
1, 6
-
22 0 0 1st output -
1, 6
-
23 0 0 2nd output -
1, 6
-
24 0 0 Transmission -
1, 6
-
25 0 0 Time signal -
1, 6
-
26 0 0 External drive -
1, 6
-
27 0 0 Pattern select -
1, 6
-
28 0 0 Time unit 2 -
1, 6
-
2b 0 0 FNC key (lock / non-lock) -
1, 7 2, 7
2c 0 0 Mode 0 (lock / non-lock) -
1, 7 2, 7
2d 0 0 Lock 1 (lock / non-lock) -
1, 7 2, 7
2e 0 0 Lock 2 (lock / non-lock) -
1, 7 2, 7
2f 0 0 Lock 3 (lock / non-lock) -
1, 7 2, 7
30 0 0 Lock 4 (lock / non-lock) -
1, 7 2, 7
31 0 0 Lock 5 (lock / non-lock) -
1, 7 2, 7
32 0 0 Lock 6 (lock / non-lock) -
1, 7 2, 7
33 0 0 Lock 7 (lock / non-lock) -
1, 7 2, 7
34 0 0 Lock 8 (lock / non-lock) -
1, 7 2, 7
35 0 0 Lock 9 (lock / non-lock) -
1, 7 2, 7
38 0 0 AL1 (ON/OFF) -
1, 8
-
39 0 0 AL2 (ON/OFF) -
1, 8
-
3a 0 0 AL3 (ON/OFF) -
1, 8
-
3b 0 0 AL4 (ON/OFF) -
1, 8
-
3c 0 0 Wait time alert -
1, 8
-
3d 0 0 Error -
1, 8
-
