7.1 Temperature Controller/Servo/Inverter Connection 7-5
DN (Individual Data)
3e 0 0 TS1 (ON/OFF) -
1, 8
-
3f 0 0 TS2 (ON/OFF) -
1, 8
-
40 0 0 TS3 (ON/OFF) -
1, 8
-
41 0 0 TS4 (ON/OFF) -
1, 8
-
42 0 0 TS5 (ON/OFF) -
1, 8
-
43 0 0 TS6 (ON/OFF) -
1, 8
-
44 0 0 TS7 (ON/OFF) -
1, 8
-
45 0 0 TS8 (ON/OFF) -
1, 8
-
46 0 0 TS9 (ON/OFF) -
1, 8
-
47 0 0 TS10 (ON/OFF) -
1, 8
-
4a Pattern No. 0 RUN -
1, 9 2, 1
4b 0 0 STOP -
1, 9 2, 1
4c 0 0 RESET -
1, 9 2, 1
4d 0 0 END -
1, 9
-
4e 0 0 ADV -
1, 9 2, 1
4f 0 0 CONST -
1, 9 2, 4
50 0 0 MAN1 -
1, 9 2, 3
51 0 0 MAN2 -
1, 9 2, 3
52 0 0 WAIT -
1, 9
-
53 0 0 AT -
1, 9 2, 6
54 0 0 FNC key LOCK -
1, 9
-
55 0 0 M/S -
1, 9
-
56 0 0 FAST -
1, 9
-
57 0 0 SV Up -
1, 9
-
58 0 0 SV Down -
1, 9
-
5b 0 0 Constant SV 4
1, 1 2, 4
Address Denotations
Name
Decimal
Place
Command
Address (BIN) Parameter 1 (BCD) Parameter 2 (BCD) Read Write
Address Denotations
Name
Decimal
Place
Command
Address (BIN) Parameter 1 (BCD) Parameter 2 (BCD) Read Write
00
Alarm No.
(1 to 8)
0AL1 4
1, 4 12
01
Alarm No.
(1 to 8)
0AL2 4
1, 4 12
02
Alarm No.
(1 to 8)
0AL3 4
1, 4 12
03
Alarm No.
(1 to 8)
0AL4 4
1, 4 12
06
PID No.
(1 to 8, 91 to 98)
0P 1
1, 4 13
07
PID No.
(1 to 8, 91 to 98)
0I -
1, 4 13
08
PID No.
(1 to 8, 91 to 98)
0D -
1, 4 13
0b
Parameter No.
(1 to 8)
0 Output change amount limit 1
1, 4 14
0e
Parameter No.
(1 to 8)
0 Output lower limit 1
1, 4 15
0f
Parameter No.
(1 to 8)
0 Output upper limit 1
1, 4 15
12
Parameter No.
(1 to 8)
0Sensor offset 4
1, 4 16
15
Parameter No.
(1 to 8)
0
Actual temperature
compensation
4
1, 4 17
18
Parameter No.
(1 to 8)
0 Wait time alert 2
1, 4 18
1b
Parameter No.
(1 to 8)
0Time signal ON time 2
1, 4 19
1c
Parameter No.
(1 to 8)
0 Time signal OFF time 2
1, 4 19
1f 1 0 Digital filter 1
1, 4 20
