7-6 7. CHINO
22 1 0 Transmission type -
1, 4 21
23 1 0 Scale (min.) 4
1, 4 21
24 1 0 Scale (max.) 4
1, 4 21
27 1 0 2nd output gap 1
1, 4 22
2a 1 0 2nd output P 1
1, 4 23
2b 1 0 2nd output I -
1, 4 23
2c 1 0 2nd output D -
1, 4 23
2f 1 0 2nd output change amount limit 1
1, 4 24
32 1 0 2nd OL 1
1, 4 25
33 1 0 2nd OH 1
1, 4 25
36 1 0 2nd deadband 1
1, 4 26
39 1 0 2nd PV output error 1
1, 4 27
3c 1 0 2nd output normal/reverse -
1, 4 28
3f 1 0 2nd pulse cycle -
1, 4 29
42 1 0
Measurement input unit (input
type No.)
-
1, 4 30
43 1 0 Measurement input unit (unit) -
1, 4 30
46 1 0 CJ INT/EXT -
1, 4 31
49 1 0 SV decimal place -
1, 4 32
4c 1 0 PV decimal place -
1, 4 33
4f 1 0 Alarm filter -
1, 4 34
52
Alarm No.
(1 to 4)
0Alarm mode -
1, 4 35
53 1 0 Alarm deadband 4
1, 4 35
56 1 0 Deadband 1
1, 4 36
59 1 0 Pulse cycle -
1, 4 37
5c 1 0 Zero 1
1, 4 38
5d 1 0 Span 1
1, 4 38
5e 1 0 Deadband 1
1, 4 38
61 1 0 Output preset 1
1, 4 39
64 1 0 Output in PV error 1
1, 4 40
67 1 0 Output normal/reverse -
1, 4 41
6a 1 0 Linear range (zero) 4
1, 4 42
6b 1 0 Linear range (span) 4
1, 4 42
6e 1 0 Linear scale (min.) 4
1, 4 43
6f 1 0 Linear scale (max.) 4
1, 4 43
72 1 0 ARW (lower limit) 1
1, 4 44
73 1 0 ARW (upper limit) 1
1, 4 44
76
Parameter No.
(1 to 8)
0 AT2SV (ON/OFF) -
1, 4 45
77
Parameter No.
(1 to 8)
0AT2SV 4
1, 4 45
7a
Parameter No.
(1 to 7)
0Break SV 4
1, 4 46
7d
Parameter No.
(1 to 8)
0 AT3SV (ON/OFF) -
1, 4 47
7e
Parameter No.
(1 to 8)
0AT3SV 4
1, 4 47
81 1 0 AT start direction -
1, 4 48
84 1 0 SV at reset 4
1, 4 49
87 1 0 SV display scale (min.) 4
1, 4 50
88 1 0 SV display scale (max.) 4
1, 4 50
8b 1 0
Thermocouple type
(thermocouple No.)
-
1, 4 51
8c 1 0 Thermocouple type (unit) -
1, 4 51
8f 1 0 SV scale (min.) 4
1, 4 52
90 1 0 SV scale (max.) 4
1, 4 52
Address Denotations
Name
Decimal
Place
Command
Address (BIN) Parameter 1 (BCD) Parameter 2 (BCD) Read Write
