16.2 Temperature Controller/Servo/Inverter Connection 16-37
F-MPC50/F-MPC55/F-MPC60B (UM4Bx, UM42xx, UM43xx)
Communication setting
The communication parameters can be set using keys attached to the front of the power monitor unit.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
* The communication parameter (stop bit) is fixed to 1 bit.
F-MPC60B (UM44xx)
Communication setting
The communication parameters can be set using keys attached to the front of the power monitor unit.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
* The communication parameter (stop bit) is fixed to 1 bit.
FePSU
Communication setting
The communication parameters can be set using keys attached to the front of the power monitor unit.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
*1 The communication function of FePSU can be selected at the time of purchase. Select a model on which “FePSU mode” is available.
*2 The communication parameter (stop bit) is fixed to 1 bit.
Setting Code Item Setting Example
90 RS-485 address setting
Loc: communication not used
01 to 99
01
91 RS-485 transmission specification
7SEG LED
1927o
Data length
7: 7 bits
8: 8 bits
Baud rate
48: 4800 bps
96: 9600 bps
192: 19200 bps
Parity
n: None
E: Even
o: Odd
Setting Code Item Setting Example
90 RS-485 address setting
Loc: communication not used
01 to 99
01
91 RS-485 transmission specification
7SEG LED
1927o
Data length
7: 7 bits
8: 8 bits
Baud rate
48: 4800 bps
96: 9600 bps
192: 19200 bps
Parity
n: None
E: Even
o: Odd
Type Parameter Display Item Setting Example
SEL-c
Adr.
Communicating station number
Loc: Communication not used
01 to 99
01
bud
Baud rate
4.8: 4800 bps
9.6: 9600 bps
19.2: 19200 bps
19.2
cbit.
Data length, parity
8n: Data length 8 bits, without parity
8E: Data length 8 bits, even parity
8o: Data length 8 bits, odd parity
7n: Data length 7 bits, without parity
7E: Data length 7 bits, even parity
7o: Data length 7 bits, odd parity
7o
LtY.
Communication Mode
Psu: FePSU mode
*1
_PP: PPM(B) mode
Psu
