16-38 16. Fuji Electric
F*JF-R
Communication setting
The communication parameters can be set using keys attached to the front of the digital regular electricity meter.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
* The communication parameter (stop bit) is fixed to 1 bit.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
*1 When a device memory other than status is used, set the decimal point of the numerical display part to “3”.
*2 “0” is stored in the address for which “(Blank)” is indicated in the table below.
*3 For setting data, see “18 (Setting Data)” described below.
18 (Setting Data)
Type Item Setting Example
Communication
setting
Address 01 - 99 01
Baud Rate 4800bps / 9600bps / 19.2 kbps
19.2 kbps
Data Length 7
/ 8 bits 7 bits
Parity Bit None / Even / Odd
Odd
Device Memory TYPE Remarks
00
(data request of circuit No. 1 to 4)
*1
00H Double-word, read only
01
(data request of circuit No. 5 to 8)
*1
01H Double-word, read only
02
(data request of circuit No. 9, 10 or E)
*1
02H Double-word, read only
03
(Data request of the minimum/maximum voltage, power factor of circuit 1 to 10, and
invalid power)
*1 *2
03H Double-word, read only
09 (model code) 09H Read only
10 (operation status) 0AH Read only
11
(pre-alarm value)
*1
0BH Double-word, read only
12
(current value measurement data)
*1 *2
0CH Double-word, read only
13
(integrated value data)
*1 *2
0DH Double-word, read only
14
(demand measurement data)
*1 *2
0EH Double-word, read only
15
(data of a maximum value of demand measurement)
*1 *2
0FH Double-word, read only
16
(historical data 1)
*1 *2
10H Double-word, read only
17 (historical data 2) 11H Double-word, read only
18
(setting data)
*3
12H Double-word
Address F-MPC04/F-MPC04P/F-MPC04S FePSU F-MPC30/F-MPC50/F-MPC55V/F-MPC60B
00zz Wiring method (voltage measured) (Blank) CT primary rated current
01zz
Ratio of VT 1 (primary voltage)
*1
(Blank) Ratio of VT (primary voltage)
02zz
Ratio of VT 1 (secondary voltage)
*1
(Blank) Ratio of VT (secondary voltage)
03zz Demand average time Demand average time Rated frequency
04zz Frequency (Blank)
Protective INST (current setting)
*2
05zz Number of applicable circuits (Blank) Protective INST (output setting)
06zz Pulse multiplying factor (Blank)
Protective DT (current setting)
*2
07zz
Ratio of VT 2 (primary voltage)
*1
(Blank)
Protective DT (operation time)
*2
08zz
Ratio of VT 2 (secondary voltage)
*1
(Blank)
Protective DT (output setting)
*2
09zz Number of turns for CT2 secondary line (Blank) Protective OC (current setting)
10zz
CT primary current
*1
(Blank) Protective OC (characteristic)
11zz OCG sensitivity current (Blank)
Protective OC (time magnification)
*2
