16.2 Temperature Controller/Servo/Inverter Connection 16-39
12zz
OCG operation time
*2
(Blank) Protective OC (output setting)
13zz Load pre-alarm sensitivity current (Blank)
Protective OCA overcurrent pre-alarm
(current setting)
14zz Load pre-alarm operation time (Blank)
Protective OCA overcurrent pre-alarm
(operation time)
15zz Automatic display circuit register (Blank)
Protective OCA overcurrent pre-alarm
(output setting)
16zz ZCT select (Blank)
Protective OCG (51G) (current setting)
*3
17zz VT select (Blank) Protective OCG (51G) (characteristic)
18zz (Blank) (Blank)
Protective OCG (51G) (time magnification)
*2
19zz (Blank) (Blank) Protective OCG (51G) (output setting)
20zz Phase selection (Blank)
Protective OCG (50G) (current setting)
*2
21zz Power alarm upper limit Power alarm upper limit
Protective OCG (50G) (operation time)
*2
22zz
Integral power pulse multiplying factor
*4
Pulse multiplying factor
*4
Protective OCG (50G) (output setting)
23zz Load pre-alarm operation value
Load pre-alarm
operation value
Protective DG (DG/OCG) (current setting)
*3
24zz Load pre-alarm operation time (Blank)
Protective DG (DG/OCG) (operation time)
*3
25zz Leak pre-alarm sensitivity current
Leak pre-alarm
sensitivity current
Protect DG (DG/OCG) (output setting)
26zz
Leak pre-alarm operation time
*2
Leak pre-alarm
operation time
*2
Protective DG (DG/OCG) (maximum
sensitivity phase angle)
27zz OCG sensitivity current
Leak alarm sensitivity
current
Protective DG (DG/OCG) (voltage setting)
*2
28zz
OCG operation time
*2
Leak alarm operation
time
*2
Protective DG (DG/OCG) (selected from DG
or OCG)
29zz Operation type for power
Operation type for
power
Protective 0 V (voltage setting)
30zz (Blank) Phase R input position
Protective 0 V (operation time)
*2
31zz (Blank)
History of turning
breaker ON
Protective 0 V (output setting)
32zz (Blank)
Show/hide cause of
trouble
Protective UV (voltage setting)
33zz (Blank)
Phase interruption
alarm of neutral line
Protective UV (operation time)
*2
34zz (Blank) Alarm output 1 Protective UV (output setting)
35zz (Blank) Alarm output 2 Protective UV2 (voltage setting)
36zz (Blank) Contact input 1
Protective UV2 (operation time)
*2
37zz (Blank) Contact input 2 Protective UV2 (output setting)
38zz (Blank) (Blank) Protective UV operation setting
39zz (Blank) Rated current (IN) Voltage establishment VR (voltage setting)
40zz (Blank) Current demand time
Voltage establishment VR (operation time)
*2
41zz (Blank) Voltage demand time Voltage establishment VR (output setting)
42zz (Blank) Power demand time
Protective OVG (voltage setting)
*2
43zz (Blank) Leak demand time Protective OVG (operation time)
44zz (Blank) (Blank) Protective OVG (output setting)
45zz (Blank) (Blank) ZPD/EVT selection
46zz (Blank) (Blank) Phase interruption relay
Address F-MPC04/F-MPC04P/F-MPC04S FePSU F-MPC30/F-MPC50/F-MPC55V/F-MPC60B
