16-40 16. Fuji Electric
47zz (Blank) (Blank) Reverse phase relay
48zz (Blank) (Blank) Demand average time
49zz (Blank) Year setting
CB opening jam monitoring time
*3
50zz (Blank) Month setting
CB closing jam monitoring time
*3
51zz (Blank) Date setting
Monitoring trip coil TC disconnection, OFF
expedited, function application setting
52zz (Blank) Hour setting
kWh pulse constant
*5
53zz (Blank) Minute setting
kvarh pulse constant
*5
54zz (Blank) (Blank) Selective input 1 function setting
55zz (Blank) (Blank) Selective input 2 function setting
56zz (Blank) (Blank) Selective input 3 function setting
57zz (Blank) (Blank) Selective input 4 function setting
58zz (Blank) (Blank) Selective input 5 function setting
59zz (Blank) (Blank) Selective input 6 function setting
60zz (Blank) (Blank) Selective input 7 function setting
61zz (Blank) (Blank) Selective input 8 function setting
62zz (Blank) (Blank) Device fault detection function setting
63zz (Blank) (Blank) Fault pick-up output setting
64zz (Blank) (Blank) Transmission component 1 output setting
65zz (Blank) (Blank) Transmission component 2 output setting
66zz (Blank) (Blank) Distant/direct state output setting
67zz (Blank) (Blank) Transducer output current phase setting
68zz (Blank) (Blank) Transducer output voltage phase setting
69zz (Blank) (Blank)
Residue/CT 3rd selection (zero-phase
current)
70zz (Blank) (Blank)
Protective INST (phase N) (current setting)
*2
71zz (Blank) (Blank) Protective INST (phase N) (output setting)
72zz (Blank) (Blank) Protective OC (phase N) (current setting)
73zz (Blank) (Blank) Protective OC (phase N) (characteristic)
74zz (Blank) (Blank)
Protective OC (phase-N) (time
magnification)
*2
75zz (Blank) (Blank) Protective OC (phase N) (output setting)
76zz (Blank) (Blank)
Protective OCA overcurrent pre-alarm
(phase N) (current setting)
77zz (Blank) (Blank)
Protective OCA overcurrent pre-alarm
(phase N) (operation time)
78zz (Blank) (Blank)
Protective OCA overcurrent pre-alarm
(phase N) (output setting)
79zz (Blank) (Blank) Protective OCGA pre-alarm (current setting)
80zz (Blank) (Blank) Protective OCGA pre-alarm (operation time)
81zz (Blank) (Blank) Protective OCGA pre-alarm (output setting)
82zz (Blank) (Blank) Protective DT2 (current setting)
83zz (Blank) (Blank)
Protective DT2 (operation time)
*2
84zz (Blank) (Blank) Protective DT2 (output setting)
Address F-MPC04/F-MPC04P/F-MPC04S FePSU F-MPC30/F-MPC50/F-MPC55V/F-MPC60B
