WE2107 - Communication commands
128
I1820-1.3 enHBM
Parameter description:
Input:LIV(P1),(P2),< P3, P4, P5>;
P1: number of the limit value switch (1 …4)
P2: Limit value switch input signal (0,1,2)
0= OFF
1= net measured value
2= gross measured value
P3: logic level (0,1)
0= true (active ³ terminal signal =low, inactive ³ terminal signal =high)
1= false (active ³ terminal signal =high, inactive ³ terminal signal =low) inverted
logic of the output level
P4: Activation level (= ON_Level):
P3=0...+
99999
P5: The deactivation level (= OFF_Level)
P4=0...+
99999
If the filling / dosing functions are activated (SFU>0) than the parameters P2 and P3 will be
ignored.
Example: LIV1,2,0,9000,1000;
The command in the example sets limit value 1 (P1=1).
Limit value 1 switches to the gross measured value (P2=2).
Limit value 1 logic is true (P3=0).
Limit value 1 activates at a gross measured value >9000 (P4=9000) and deactivates at a
gross measured value <1000 (P5=1000).
