2.2 Command format
General advice:
Commands can be entered in upper or lower case letters, they are not case‐sensitive, so
either format can be used for input.
Each command entry must be concluded by a delimiter. This can either be a line feed (LF) or
a semi‐colon (;).
If an end label is all that is sent to the WE2107, the WE2107 input buffer is cleared.
The data provided in round brackets () for the commands are mandatory and must be
entered. Parameters in pointed brackets <> are optional and do not have to be provided.
The brackets themselves are not part of the input.
Text must be enclosed in quotes " ".
Responses are given in ASCII characters and terminate with LF. Output in binary characters
is the exception here (see command MSV
or COF).
Each command comprises the command shortform, one or more parameters and the end
mark.
Responses consist of ASCII characters and close with CRLF. An exception to this is binary
character output (see MSV
and COF commands).
Each command consists of the command shortform, one or more parameters and the
delimiter.
Command shortform Parameter End label
Input ABC X,Y LF or ;
Output ABC? X,Y LF or ;
LF: line feed (lf = 0a hex)
Example: MSV?;
After this command, a measured value is output.
All the ASCII characters ≤ 20
H
(blank) can appear between the command short form, the
parameters and the end mark.
For commands and parameters the following characters are allowed:
' ' '+' '‐' '.' ',' '"' '0' ...'9' 'A'...'Z' 'a'...'z'
For a input string (command PST
) the input range is : 0x1f
hex
< char < 0x7f
hex
. In this case
the string is enclosed with " ...string...".
NOTE
If the master has send a command string (query), than the master has to wait for the answer
before it send the next query.
If the master has send a command string (input), than the master has to wait for at least
10 msec. before it send the next query or command.
