Measurement status
In 4‐byte binary output, the measurement status can be transferred with the measured value
(see command COF
). The measurement status is coded bit by bit.
Content of the status byte
Possible cause
Bit 0 1= counting scale 1= counting scale is activated
Bit1 1= outside the display
range
‐160 % ... +160 % of NOV (industrial, LFT=0) ,
‐20 d ... MAX+9 d (OIML, LFT=1) ,
‐2 % ... MAX+5 % (NTEP, LFT=2)
Bit2 1= Gross value 0= net value, 1 = gross value (see also TAS)
Bit3 1= standstill 1 = standstill ( see MDT)
Bit4 1= range 2 / 3 0 = range 1, 1= range 2 / 3 (multi‐range display)
Bit5 1= Out1 active 1 = Output 1 is active
Bit6 1= Out2 active 1 = Output 2 is active
Bit7 1= Error An error occurs, read the error status with the com
mand ERR?
Example:
If standstill is active and a gross value is involved, then the content of the status byte = (8+4)
= 12 decimal (0C hex).
