Escape sequences
(Escape sequences for the print protocol )
Property Content Note
Command string ESC
No. of parameters 2
Parameter range P1: 0 … 9
P2: 0 … 255
Factory default 0
Reaction time < 15 ms
Password protection No
Relevant to legal for
trade
No
Parameter backup With command TDD1
Input Master ESC(P1),(P2); No response
Query Master ESC(P1)?;
Response WE xxx crlf 3 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
The escape sequences are used to setup the printer (see manual of the printer).
The WE has two Escape sequences:
Sequence 1:ESC, ESC0, ESC1, ESC2, ESC3, ESC4
Sequence 2:ESC, ESC5, ESC6, ESC7, ESC8, ESC9
If the ESC character is set to zero (ESCx,0) this character will not be transmitted.
To switch off the sequence 1 the command ESC0,0 has to be send.
To switch off the sequence 2 the command ESC5,0 has to be send.
ESC
