47
WE2107 - Communication commands
I1820-1.3 en HBM
Motion detection
(Motion detection)
Property Content Note
Command string MDT
No. of parameters 1
Parameter range P1= 0…4
Factory default 0
Reaction time < 15 ms
Password protection Yes
Relevant to legal for
trade
Yes
Parameter backup With command TDD1
Input Master MDT(P1); No response
Query Master MDT?;
Response WE P1crlf P1 = 1 character
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
MDT0: OFF (motion detection is switched off, unit is always displayed)
MDT1: 0.5 d / sec.
MDT2: 1.0 d / sec. ( to be set if legal for trade application)
MDT3: 2.0 d / sec.
MDT4: 5.0 d / sec.
If the stand still conditions are fulfilled than the selected unit (ENU
) will be displayed.
The digit unit (d) relates to the nominal (rated) value (NOV
) and the selected increment
(RSN
).
Example:
RSN=5, NOV=15000, weighing range = 15000 g
With MDT2 the stand still condition occurs if the deviation of the weight is less than 5 g/sec.
With MDT3 the stand still condition occurs if the deviation of the weight is less than 10 g/sec.
MDT
